An advanced polymer composite formulated to protect equipment from  extreme chemical attack and corrosion. ARC S4+ is an advanced multi-functional composite lining system  formulated for ambient and elevated temperature service. ARC S4+  yields excellent barrier properties for long-term corrosion and chemical  resistance in immersion exposures when used in a multicoat application. It is designed  to be spray applied but may also be applied by roller or brush. It is typically applied by spray,  roller or brush at a nominal thickness of 375 microns (15 mils) per coat in  a 2 coat system.

TECHNICAL DATA

• Dry Temperature Dry (Min/Max)                                                    -20 F (-29C) to 300 F (150 C)
• Wet Temperature (Min/Max)                                                          -20 F (-29C) to 140 F (60 C)
• Flexural Strength - kg/cm2 - Mpa (psi)                                        280 -28 (4,000)
• Tensile Strength - kg/cm2/Mpa (psi)                                            250 - 24 (3,500)
• Tensile Adhesion - kg/cm2 - Mpa (psi)                                        Greater than 140 - 14 (2,000)
• Water Vapor Permeability (meteric perm-cm - Perms)         1.70E-04
• Salt Fog                                                                                                >10,000 hrs
• Shore D Hardness                                                                             83
